Introduction to Surface Pumps in Egypt

Surface pumps are essential for a wide range of applications in Egypt — from agricultural irrigation and industrial water supply to residential water boosting and fire-fighting systems. Caprari, the Italian pump manufacturer with over 70 years of expertise, offers an extensive range of surface pumps designed for reliability, efficiency, and durability.

At Modern Machinery, we provide the complete Caprari surface pump range. This guide covers all Caprari surface pump series available in Egypt.

PM – PMA Series: Centrifugal Pumps

The PM and PMA series are Caprari’s standard centrifugal pumps for clean water applications, widely used in agriculture, industry, and municipal water supply.

  • Type: Horizontal centrifugal pump, single stage
  • Flow rate: Up to 150 m³/h
  • Head: Up to 95 m
  • Materials: Cast iron casing, brass impeller (PM), AISI 316 stainless steel (PMA)
  • Applications: Water supply, irrigation, pressure boosting, industrial circulation

PMXT Series: High-Temperature Centrifugal Pumps

The PMXT series is designed for high-temperature fluid handling applications.

  • Type: Horizontal centrifugal pump, high temperature
  • Flow rate: Up to 120 m³/h
  • Head: Up to 85 m
  • Temperature: Up to 120°C
  • Applications: Hot water circulation, boiler feed, industrial heating systems

HMU Series: Horizontal Multi-Stage Pumps

Multi-stage pumps deliver higher pressures than single-stage pumps, making them ideal for high-lift applications.

  • Type: Horizontal multi-stage centrifugal pump
  • Flow rate: Up to 50 m³/h
  • Head: Up to 150 m
  • Materials: Stainless steel impellers and casing
  • Applications: High-pressure water supply, boiler feed, irrigation networks, pressure boosting

MEC Series: Self-Priming Pumps

Self-priming pumps can handle air and water mixtures, making them ideal for applications where the pump is above the water level.

MEC A

  • Self-priming centrifugal pump for clean and slightly dirty water
  • Flow rate: Up to 80 m³/h, Head: Up to 70 m
  • Applications: Drainage, tank emptying, irrigation from canals

MEC MR

  • Self-priming pump with trash handling capability
  • Flow rate: Up to 100 m³/h, Head: Up to 60 m
  • Applications: Drainage with solids, wastewater handling, construction dewatering

MEC AG / MEC MG / BHG

  • Agricultural heavy-duty self-priming pumps
  • Flow rate: Up to 150 m³/h, Head: Up to 55 m
  • Applications: Agricultural irrigation, flood irrigation, canal water supply

MEC D

  • Self-priming drainage pump with vortex impeller
  • Flow rate: Up to 60 m³/h, Head: Up to 35 m
  • Applications: Construction dewatering, foundation drainage

NC Series: End Suction Pumps

The NC series is a robust end-suction centrifugal pump designed for industrial and agricultural applications.

  • Flow rate: Up to 200 m³/h, Head: Up to 90 m
  • Back pull-out design for easy maintenance
  • Applications: Industrial water supply, irrigation, fire fighting systems

BHR Series: Vertical Multi-Stage Pumps

Vertical multi-stage pumps save floor space while delivering high pressures.

  • Flow rate: Up to 30 m³/h, Head: Up to 200 m
  • Compact vertical design
  • Applications: Pressure boosting, boiler feed, high-rise building water supply

SCC Series: Split Case Pumps

Split case pumps are designed for high-flow, medium-head applications with easy maintenance access.

  • Flow rate: Up to 500 m³/h, Head: Up to 120 m
  • Horizontally split casing for easy internal access
  • Applications: Large irrigation schemes, municipal water supply, fire fighting

CVX Series: Vertical Multi-Stage Pumps

CVX vertical multi-stage pumps are designed for high-pressure applications in compact spaces.

  • Flow rate: Up to 25 m³/h, Head: Up to 250 m
  • Stainless steel construction
  • Applications: Pressure boosting, boiler feed, water treatment, industrial washing

HV Series: Vertical Multistage Pumps

Heavy-duty vertical multi-stage pumps for demanding high-pressure applications.

  • Flow rate: Up to 60 m³/h, Head: Up to 180 m
  • Applications: Water supply, irrigation, industrial processes

MD Series: Centrifugal Process Pumps

Process pumps designed for industrial applications requiring compliance with international standards.

  • Flow rate: Up to 80 m³/h, Head: Up to 100 m
  • EN 22858 / ISO 5199 compliant
  • Applications: Chemical industry, petrochemical, industrial processes

Why Caprari Surface Pumps?

  • Italian Quality: Over 70 years of pump engineering excellence.
  • Comprehensive Range: From simple centrifugal pumps to high-pressure multi-stage systems.
  • Energy Efficient: Advanced hydraulic designs reduce operating costs.
  • Durability: Built with high-quality materials for long service life.
  • Local Support: Full range available through Modern Machinery in Cairo.
